齒輪是互相嚙合的有齒的機械零件，它在機械傳動乃整個機械行業，日常生活中都有著很廣泛的應用，齒輪的應用歷史悠久，今也是機械行業中不可或缺的重要零件。接下來導軌絲杠廠家為您講解一下齒輪齒條的分類及主要應用。

Gear is a mechanical part with teeth that mesh with each other. It is widely used in mechanical transmission and even in the whole mechanical industry and in daily life. The application of gear has a long history, and it is also an indispensable and important part in the mechanical industry. Next, the guide screw manufacturer will explain the classification and main application of gear and rack for you.

01

01

齒輪齒條工作原理：

Operating principle of gear and rack:

齒輪齒條工作原理是將齒輪的回轉運動轉變?yōu)辇X條的往復直線運動，或將齒條的往復直線運動轉變?yōu)辇X輪的回轉運動。

The working principle of gear and rack is to change the rotary motion of gear into the reciprocating linear motion of rack, or the reciprocating linear motion of rack into the rotary motion of gear.

02

02

齒輪分類：

Gear classification:

平行軸齒輪

Parallel shaft gear

正齒輪&齒條

Spur gear&rack

內齒輪&斜齒齒輪

Internal gear&helical gear

斜齒齒條&人字齒輪

Helical rack&herringbone gear

交錯軸齒輪

Staggered shaft gear

直齒錐齒輪

Straight bevel gear

弧齒錐齒輪&零度錐齒輪

Spiral bevel gear&zero degree bevel gear

交錯軸齒輪

Staggered shaft gear

圓柱蝸桿副&交錯軸斜齒齒輪

Cylindrical worm pair&staggered helical gear

其他特殊齒輪

Other special gears

鼓型蝸桿副&準雙曲面齒輪

Drum worm pair&hypoid gear

面齒輪

Face gear

03

03

齒輪齒條機構：

Rack and pinion mechanism:

齒輪齒條機構是由齒輪和齒條構成的，齒輪前面我們有很詳細的講解。齒條分直齒齒條和斜齒齒條，齒條的齒廓為直線而非漸開線，相當于分度圓半徑為無窮大圓柱齒輪。

The rack and pinion mechanism is composed of gear and rack. We have explained the gear in detail before. The rack is divided into straight rack and helical rack. The tooth profile of the rack is straight rather than involute, which is equivalent to a cylindrical gear with an infinite radius of indexing circle.

齒條的主要特點

Main features of rack

由于齒條齒廓為直線，所以齒廓上各點具有相同的壓力角，且等于齒廓的傾斜角，此角稱為齒形角，標準值為20°。

Because the rack tooth profile is straight, each point on the tooth profile has the same pressure angle and is equal to the inclination angle of the tooth profile. This angle is called the tooth profile angle, and the standard value is 20 °.

與齒頂線平行的任一條直線上具有相同的齒距和模數。

Any straight line parallel to the tooth top line has the same tooth pitch and modulus.

與齒頂線平行且齒厚等于齒槽寬的直線稱為分度線（中線），它是計算齒條尺寸的基準線。

The straight line parallel to the tooth top line and the tooth thickness equal to the width of the tooth slot is called the indexing line (center line), which is the reference line for calculating the size of the rack.

04

04

齒輪齒條傳動的應用范圍：

Application range of rack and pinion drive:

1、適用于快速、精準的定位機構

1. Suitable for fast and accurate positioning mechanism

2、適用于重負荷、高精度、高剛性、高速度和長行程的CNC機床、加工、切割機械、焊接機械等

2. Suitable for CNC machine tools, machining centers, cutting machines, welding machines, etc. with heavy load, high precision, high rigidity, high speed and long stroke

3、適用于工廠自動化快速移栽機械、工業機器人手臂抓取機構等

3. It is applicable to factory automatic rapid transplanting machinery, industrial robot arm grabbing mechanism, etc

齒輪齒條的分類及主要應用相關內容就講解到這里了，您對此有怎樣的疑惑或者需求，歡迎來我們網站http://www.2b4g.com咨詢！

The classification and main application of gear and rack will be explained here. What doubts or needs do you have about this? Welcome to our website http://www.2b4g.com consulting service
